CustomEvent
This help page is for CXone Studio. This information is also available for Desktop Studio.
|
Creates a custom event through which you can deliver unique data. |
Dependencies
This action is found on the API Actions palette.
Supported Script Types
|
|
|
|
|
|
|
|
Generic |
Chat | Phone | Voicemail | Work Item | SMS | Digital |
Input Properties
These properties define data that the action uses when executing.
Property |
Description |
---|---|
|
Enter a short phrase that uniquely identifies this action in the script. The caption appears on the script canvas under the action icon. |
Target Agent |
Target agent ID. |
Event Name |
Enter the name you for the custom event. Multiple events with the same name overwrite each other. Only the most recent event name is kept. This field is case-sensitive. |
PersistInMemory |
Controls whether or not CXone keeps the event in memory. |
Data |
Data payload for this event. |
Result Branch Conditions
Result branch conditions allow you to create branches in your script to handle different outcomes when an action executes.
Condition |
Description |
---|---|
Default | Path taken unless the script meets a condition that requires it to take one of the other branches. It is also taken if the action's other branches are not defined. |
OnAgentNotConnected | Path taken if the destination agent is not connected. |
